This section contains information about components of the AI Node Evaluation Kit.
The contents of our evaluation kit can slightly change in the future as we adapt to availability on the market and our customer's needs. The actual list of parts in your kit will be visible on the quote you'll receive. This is a list of all components that were in the evaluation kit at some point, and therefore compatible with AI Node.
| Image | Part Number | Description |
|---|---|---|
900-00022 rev 2 | AI Node | |
830-00024 rev 7 | AINODE ADAPTER BOARD Used to break out the AI Node IO port into Pixhawk-standard compatible connectors/pinouts. | |
115-00037 rev 04 | IO CABLE Molex Pico-Clasp 40-pin (AI Node to Pixhawk adapter board cable) | |
880-00023 rev 1 | Micro USB Micro USB to USB-A (AI Node to ground station cable for developers) | |
161-00003 rev 01 | CAMERA USB webcam manufactured by ELP | |
115-00039 rev 04 | AINODE PWR Power cable for XT60 supply | |
115-00032 rev 01 | ETH DEVELOPER Cable JST GH 9-pin to RJ45 (Ethernet to developer host) | |
115-00034 rev 01 | ETH SKYNODE Cable JST GH 9-pin to JST GH 4-pin (Ethernet connection between AI Node - Skynode, and AI Node - Microhard) | |
115-00038 rev 01 | CAMERA CABLE Cable, FFC Raspberry Pi Zero V1.3 MIPI CSI camera, 150mm | |
870-00005 rev 01 | CAMERA Sensor, Camera Module, Raspberry Pi v2 | |
880-00021 rev 01 | USB ADAPTER Adapter, USB 3.0 A to USB-C (OTG) | |
115-00036 rev 01 | PWR ADAPTER XT60 Parallel Splitter 1m2f |
